FERNO® POWER F2 Loading System with Power Drive

Ideal conditions don't exist — ice or incline, gravel or grass, slope or slush. Regardless of the challenges, being prepared and equipped to perform is critical.

Introducing the all-new FERNO® POWER F2™ loading system with power drive. Designed, engineered, and built to lift, load, and unload patients in the most challenging conditions with the touch of a button, giving emergency personnel total control while reducing injuries and staying ready for whatever comes next.

Powered for stability, consistency, and longevity.

Close-up of the Ferno Power F2 loading the Ferno Power X2 Ambulance Cot — Power Drive technology lifts and loads patients at the touch of a button to reduce strain and injury on paramedics

Close-up of the Ferno Power X2 controls while with the Ferno Power F2 loading system — Power Drive mode can be controlled using the simple touch controls from the POWER X2 Cot, the FERNO Connect, and / or the POWER F2 Carriage

Close-up of the Ferno Power F2 lifting the Ferno Power X2 Ambulance Cot — 700 lbs lift capacity eliminates the need for paramedics to bear the weight, ensuring safer and more efficient patient transportation

Close-up of the Ferno Power X2 being manually loaded into the Ferno Power F2 loading system — Manual mode enables complete loading and unloading of patients for everyday use or in the event of power loss

Eliminating barriers for a whole new powered experience.

Close-up of the Ferno Power X2 connecting with the Ferno Power F2 loading system with power drive — Universally cross-compatible with the majority of manual and power cots, CrossLock ensures seamless integration with existing products

Close-up of the Ferno Power F2 SceneBright LED lights below the carriage — SceneBright LED lights automatically illuminate the ground below the carriage when deployed from the vehicle, ensuring optimal visibility

Close-up of the back of the Ferno Power F2 EnduraCharge 36-volt LiFePO4 battery — Built-in, spare EnduraCharge 36.3-volt LiFePO4 Battery with integrated charging provides a consistent, reliable back-up power for uninterrupted operation

Take control.

The FERNO Connect touchscreen console is the central hub, providing full control and insight into the POWER X2 and POWER F2 systems.

Action screens in combination with directional LED lights visually guide paramedics during loading and unloading for efficient and safe operation
Battery charging status for both POWER F2 and POWER X2
Alerts prompt operators and technicians to error states

Cycle counts for both POWER F2 and POWER X2 to help with maintenance and extend equipment life
Fleet and asset management streamline operations and maximize efficiency
Flexible and easy mounting options based on vehicle configuration

Detail focused.

SPECIFICATIONS

Overall Length

88" / 2235 MM

WIDTH

24.5" / 622 MM

WEIGHT

199.5 lbs / 90.45 kg (Total Weight including 2 lbs for Ferno Connect)

16.5 LBs / 7.5 kg (Floor Plate Assembly)

115 lbs / 52.1 kg (FIXED RAIL Assembly)

66 lbs / 29.9 kg (Carriage Assembly)

Maximum Lift Capacity*

700 lbs / 318 kg

Recommended Loading Height

up to 36"

BATTERY

36.3V (2.6Ah) LITHIUM IRON PHOSPHATE (LiFePO4)

*MAXIMUM LIFT CAPACITY represents patient weight and accessories. Ferno® safe working load of 870lbs (395kg) represents the sum of the cot total weight with accessories and patient

FERNO® reserves the right to change specifications without notice.

COMPLIANCE

NZS-4535*

BS EN-1789*

SAE J3027**

The FERNO® Power F2™ is compliant with the above standards when used with:

FERNO® POWER X2™ AMBULANCE COT
STRYKER® POWER-PRO™ XT AMBULANCE COT
STRYKER® POWER-PRO™ 2 AMBULANCE COT
